Product FeaturesAutomated: automated production/Prodcut consistencyUltra-Safe: Explosion-proof / No leakageStable: Low IR / High CRD/ Discharge SteadilyCustomized: Customer Demand CustomizationSuper Long: Ultra-long life cycleEnvironmentally Friendly: Passed environmental/system certification&
Automated: automated production/Prodcut consistency
Ultra-Safe: Explosion-proof / No leakage
Stable: Low IR / High CRD/ Discharge Steadily
Customized: Customer Demand Customization
Super Long: Ultra-long life cycle
Environmentally Friendly: Passed environmental/system certification
| Specification Parameters | |
|---|---|
| Nominal Capacity | 304Ah |
| Nominal Voltage | 3.2V |
| Initial IR | ≤0.5m |
| Weight | 5.49±0.3kg |
| Charging Cut-off Voltage | 3.65V |
| Discharging Cut-off V oltage | 2.5 V T >0℃ 2.0 V T ≤0℃ |
| Discharging Temperature | - 30~60℃ |
| Storage Temperature | 0~35℃ |
| Model Name | LF304 |
| Cycle Life | ≥3500 cycles |
| Standard Charging Power | 0.5C/0.5C |
| Standard/Max. continuous Discharging Power | 0.5C/1C |
| Height(H) with terminal | 208.8±1.0mm |
| Height(h) without terminal | 204.5±1.0mm |
| Length | 173.5±1.0m |
| Thickness | 72.0±1.0m |
